SX9376
SX9376 is a member of the Semtech PerSe Connect product line which enables superior connectivity in the latest 5G and Wi-Fi applications. It provides 8-channels to support advanced radio frequency (RF) control for performance optimization and worldwide Specific Absorption Rate (SAR) regulation compliance. Its class-leading sensing performance and ultra-high DC offset compensation capability make it the optimal solution for a wide range of consumer connected devices.
Features
- 8-channel sensor input specially designed for SAR applications
- Patented on-chip smart human sensing
- Capacitance resolution down to 0.74aF
- Capacitance offset compensation up to 600pF
- ~1.8V input supply voltage
- Automatic calibration
- Ultra-low power consumption
- I2C serial interface (I3C capable)
- -40°C to +85°C operation
- Compact package size
- Pb & halogen free, RoHS/WEEE compliant
- モバイル
- Tablet
- Laptop
- Hotspot
アプリケーション
Packaging
- 1.8mmX1.9mmX0.55mm QFN
Order Codes
- SX9376IULTRT
