放送ビデオ
Semtechは、シリアルデジタルインターフェイス（SDI）技術のイノベーターとして、先進的な超高精細（UHD）SDIソリューションをいち早く市場に投入ました。今日では、実績のあるUHD-SDI、3G-SDI、高精細（HD）SDI、標準精細（SD）SDIの各技術をリードしており、放送業界の実際の課題に特化した、世界で最も先進的なソリューションを提供しています。市場投入までの時間の短縮と設計リスクの低減を目標として、常にパフォーマンス、到達距離、シグナルインテグリティの限界を押し広げるよう尽力しています。UHD-SDIは、ルーターやカメラ、モニター、スイッチャーなどを含むUHDTV-1やUHDTV-2のインフラストラクチャに最適です。
実際、おそらくどのテレビ放送でも、Semtechの部品が使用されていると考えられます。
.png)
.png)
パラメトリック検索
直感的な検索ツールを使用して、正確な設計ニーズと仕様に合った製品を見つけて比較できます。
プロトタイプ作成と制作に役立ち、ダウンロード可能な豊富なリソースとデータシートを活用しましょう。
Login or register for mySemtech to gain access to restricted product documentation and to add documents to your Watch List for update alerts
関連情報
GS12170 SDI / HDMIブリッジには、3つの構成可能な…
この動画ではGS12170 SDI/HDMIを紹介...
Semtechシグナルインテグリティ製品グループ…
Whether you are watching an action replay of a baseball game on a giant screen at a stadium, a movie on your large-screen TV or streaming a video on your laptop computer, a high-quality audiovisual (AV) experience is always expected. Ultra-High-Definition Serial Digital Interface (UHD-SDI) and High-Definition Multimedia Interface (HDMI) are two standards for digital AV transmission. UHD-SDI standardizes the transmission of uncompressed and unencrypted digital AV signals over coaxial or fiber optic cables. HDMI is a digital interface for transmitting high-definition, high-speed digital multi-track audio and uncompressed video signals from HDMI-compliant sources to AV displays. Even though they both can transport ultra-high-definition AV signals from a source to a display, HDMI is preferred to connect consumer gadgets such as computers, gaming consoles, Blu-ray/DVD players, televisions, projectors, etc. UHD-SDI is preferred for high-end applications such as professional indoor/outdoor video production and television broadcasts because it supports long-range transmission and a rugged connection with the help of a physical lock mechanism at each end of the cable. UHD-SDI coaxial cable can transfer signals up to 300 feet, whereas HDMI cables struggle with excessive signal degradation even within 50 feet. These two interfaces can be used together via an HDMI-SDI or SDI-HDMI converter. For example, as shown in figure 1, an HDMI display would be used for confidence monitoring of an SDI stream to avoid the need to use specially calibrated SDI-specific displays.
Circuit Protection for HDMI-SDI/SDI-HDMI…
今すぐ読む
I designed my first product using the Serial Digital Interface (SDI) back in 1996, and little did I know that this fledgling coax-based video interface standard would dominate my career for the next 20+ years. Back then, SDI was limited to carrying Standard Definition (SD) digital video at 270 Megabits per second (Mbps), but would evolve to higher and higher data rates to carry High Definition 720p, 1080i and 1080p, and most recently 4K Ultra High Definition (UHD) video, at cable lengths that were not thought possible. The convenience of a low cost single conductor coaxial copper cable, capable of carrying 4K video up to 100m has meant that SDI has become the de facto AV connectivity of choice in markets such as broadcast, Pro AV, medical and surveillance.
今すぐ読む
