RClamp1631PQ
RClamp®1631PQ is a low-capacitance RailClamp transient voltage suppressor (TVS) for electrostatic discharge (ESD) and electrical overstress (EOS) protection of high-speed interfaces in automotive applications. RClamp1631PQ is designed to provide minimal capacitive loading and low-harmonic generation on RF antenna lines.
Features
- High ESD withstand voltage: ±30kV (contact & air) per IEC 61000-4-2
- Survives short-to-battery fault conditions in 12V and 24V systems
- Working voltage: 16V
- Low harmonic distortion
- Low ESD clamping voltage
- Low capacitance: 0.4pF maximum
- Qualified to AEC-Q100 (Grade 1) and AEC-Q101
- Solid-state silicon-avalanche technology
- RF radio antennas
- Automotive ethernet
- CAN bus
アプリケーション
Packaging
- DFN 1.60 x 1.00 x 0.53mm 2-Lead
Order Codes
- RClamp1631PQTCT
