概要

RClamp0584P has a maximum capacitance of only 0.20 pF between I/O pins and GND. ESD characteristics are highlighted by high ESD withstand voltage (±10kV Contact per IEC 61000-4-2), each device will protect four lines operating at 5.5 volts.

Packaging

  • DFN 0.60x0.30x0.25mm 2-Lead

Order Codes

  • ​RClamp0584P.C : Pb-free, Halogen-free, RoHS/WEEE-compliant, 3,000 pcs.
  • RClamp0584P.A: Pb-free, Halogen-free, RoHS/WEEE-compliant, 5,000 pcs.
  • RClamp0584P.N: Pb-free, Halogen-free, RoHS/WEEE-compliant, 10,000 pcs.

PB Free/ROHS

Learn More →

Features

  • Transient Protection to
    • IEC 61000-4-2 (ESD) ±15 kV (Air), ±10kV (Contact)
    • IEC 61000-4-5 (Lightning) 5A (8/20μs)
  • Protects four High-Speed Data Lines
  • Package design optimized for high speed lines
  • Working voltage: 5.5V
  • Low clamping voltage
  • Low capacitance: 0.20pF maximum (I/O to GND)

アプリケーション

  • Thunderbolt 4
  • USB Type-C
  • USB 3.2 and USB4
