SC1109
Not Recommended for New Designs
Not recommended for new designs.
Features
- Dual linear controllers
- LDOs track input voltage within 200 mV (function of the MOSFETs used) until regulation
- Integrated drivers
- Power-good signal (SC1109A, SC1109B)
- Soft start
- Lossless current sense
- Programmable over-current limit (SC1109C)
- Fixed frequency 200 kHz (SC1109A, SC1109C)
- Fixed frequency 500 kHz (SC1109B)
- SO-16 package
- Pentium® III Motherboards
- Triple power supplies
