SC1185
Not Recommended for New Designs
Not recommended for new designs.
Features
- Synchronous design, enables no-heatsink solution
- 95% efficiency (switching section)
- 5-bit DAC for output programmability
- On-chip power-good function
- Designed for Intel Pentium® II requirements
- 1.5 V, 2.5 V @ 1.25% for linear section
- 1.265 V ± 1.5% reference available
- 24-lead SO package. Lead free option available. Lead free product is fully WEEE and RoHS compliant.
- Pentium® II microprocessor supplies
- Flexible motherboards
- 1.3 V – 3.5 V microprocessor supplies
- Programmable triple power supplies
アプリケーション
Packaging
- SOIC-24
Order Codes
- SC1185CSW.TR: 1,000 pcs. Tape & Reel
- SC1185CSW.TRT: Lead-Free, RoHS and WEEE Compliant, 1000 pcs. Tape & Reel Only
Pb(Lead)-Free/RoHS-Green Info
Base Part Number (1)
SC1185
Part Description
PROGRAMABLE SYNCHRONOUS DC/DC CONVERTER, DUAL LDO CONTROLLER
