Semtech、放送映像用新チップソリューション「GS12170 SDI/HDMI Bridge」を発表
Reducing time-to-market, industry-first chip eliminates need for costly Field-Programmable Gate Array (FPGA) components
CAMARILLO, Calif., Mar. 24, 2021 — Semtech Corporation (Nasdaq: SMTC), a leading supplier of high-performance analog and mixed signal semiconductors and advanced algorithms, today announced its new, industry-first GS12170 SDI/HDMI Bridge chip which enables low power, seamlessly connected, uncompressed 4K-video, multichannel audio, and large amounts of metadata to cross the barrier between HDMI and SDI without requiring an FPGA. The GS12170 is a single-chip solution for converting HDMI signals to SDI (or vice versa) and when paired with Semtech’s industry-leading 12G UHD-SDI reclocking cable equalizers and cable drivers, the chip allows for a long-reach, high-performance, low power SDI connection.
The GS12170 is the enabler to move from HD to 4K for low-cost HDMI extenders, by eliminating the need for costly FPGAs. Reach is over 100m of UHD-rated coaxial cable when paired with Semtech’s GS12341 reclocking SDI adaptive UHD-SDI cable equalizer and GS12281 reclocking UHD-SDI cable driver, all while offering significantly lower power consumption than previously possible.
GS12170 features include:
- Conversion of HDMI to SDI, SDI to HDMI or SDI to SDI (gearbox) in a single chip
- Full support for video formats compatible with SDI from HD-SDI to 12G UHD-SDI, including both single-link and multilink connections
- Support for formats up to 4Kp60 4:2:2 YCbCr 10-bit (UHDTV-1)
- Support for RGB, 4:4:4 and 12-bit interfaces
- Automatic HDMI and SDI audio embedding and de-embedding
- Dedicated I2S audio pins for up to 16-channels of audio at 48kHz sampling frequency; 8-channels of audio at 96kHz sampling frequency
- Automatic handling and conversion between SMPTE ST 352 Stream ID and CTA 861 Infoframes
- Dedicated high-speed ancillary data interface for handing large metadata payloads
- Dedicated SMPTE timecode generation and insertion
Combining the benefits of low-power operation with a small footprint, the GS12170 is ideal for integration in 4K monitors, cameras, extenders, format converters, production switchers, and other AV equipment. In addition to direct interfacing to HDMI ISPs, the GS12170 can be used to add low-cost HDMI confidence monitoring to applications where dedicated SDI monitoring may be cost prohibitive. Learn more about GS12170 SDI/HDMI Bridge on the Semtech website.
Semtech provides detailed device specifications, reference design kits and reliability qualification reports through the mySemtech Document Portal. To request pricing and availability information, please contact a Semtech sales manager or one of our franchised channel partners via www.semtech.com/sales.
About Semtech
Semtech Corporation is a leading supplier of high performance analog and mixed-signal semiconductors and advanced algorithms for infrastructure, high-end consumer and industrial equipment. Products are designed to benefit the engineering community as well as the global community. The Company is dedicated to reducing the impact it, and its products, have on the environment. Internal green programs seek to reduce waste through material and manufacturing control, use of green technology and designing for resource reduction. Publicly traded since 1967, Semtech is listed on the Nasdaq Global Select Market under the symbol SMTC. For more information, visit www.semtech.com.
